For aggregate producers, quarry owners and construction material factories, a 100 tons per hour crushing production line is one of the most widely used and cost-effective capacity scales. It balances investment cost, operation difficulty and output efficiency, and can meet the needs of road construction, building aggregates, concrete mixing stations and quarry projects.

As a professional manufacturer focused on crushing and screening equipment, Westlakemachinery provides standard and reliable 100 TPH crushing line configurations for different materials, especially for soft rock (limestone) and hard rock (basalt, granite).

Typical 100 TPH Crushing Line Configuration

A complete 100 TPH crushing production line generally includes: vibrating feeder, primary crusher, secondary crusher, vibrating screen, belt conveyors and control system. The specific equipment model depends on material hardness and finished product requirements.

1. For low-hardness materials (limestone, dolomite)

This is the most common application. Limestone is easy to crush, so the configuration is simple and efficient.

• Vibrating Feeder: ZSW 380×95

• Primary Crusher: PE 600×900 Jaw Crusher

• Secondary Crusher: PF 1210 Impact Crusher

• Vibrating Screen: 3YK1860

• Belt Conveyors: matching width and length

•


This line can stably reach 80–120 TPH, with cubic-shaped aggregates, low needle flakes, and high quality for construction use. It features low energy consumption, easy maintenance and high cost performance.

2. For high-hardness materials (basalt, granite, diabase)

• Vibrating Feeder: ZSW 380×95

• Primary Crusher: PE 600×900 Jaw Crusher

• Secondary Crusher: CSB160 Cone Crusher

• Vibrating Screen: 3YK1860

• Belt Conveyors: complete set

•


This configuration ensures stable output, less wear on parts, longer service life and lower long-term operating cost. It is widely used in high-grade road and railway projects.

Why Choose Westlakemachinery?

• Stable output, actual capacity reaches nominal value

• High wear-resistant parts, reducing downtime

• Compact layout, easy installation and low foundation cost

• Customizable for dry or wet production, mobile or fixed type

• Professional after-sales support, global spare parts supply

•
